Tail mechanics!

Here’s a shot of my first “4-way tentacle control”. I can’t say enough about the DVDs from the Stan Winston School of Character Arts! I’ve watched most of 3 DVDs, and learned so much, including how to machine parts for the tentacle control, and how to 3D print parts for the eye mechanics.  Here, I’ve combined the two by 3D printing the spacing discs (think “vertebrae”).

In the Stan Winston terminology, anything that looks like a tail that swings back and forth plus up and down is referred to as a tentacle control.  This is the basic mechanism for the chest burster in Alien!

Read More

First dragon parts

Its been a few months since I did any 3D printing, but now that I’m exploring the inner workings of the dragon kingdom, I’m back into it.

This morning I designed some eyes, a pulley (which I ultimately decided I wouldn’t use, but went ahead to try the part concept after all), and a small plate for mounting eye parts and mechanics.

It went pretty well.   Read More
